Flash Products

A650 Barricade Lights

Barricade, airside construction and airport warning light

The A650 solar barricade light and airside construction light meets FAA and ICAO requirements for general purpose marking, taxiway and runway closures and unserviceability marking needs. Lower cost than traditional airport lighting, the A650 solar airfield light doesn’t sacrifice quality, durability or service.



Our high-quality batteries have a lifetime of 2500 cycles or more, equating to 7 years with no maintenance. A650 airport warning lights have an expected lifetime of over 20 years.



Applications

  • Airside construction
  • Barricade lights
  • Taxiway and runway closures
  • Unserviceability lighting



Easy Installation and Relocation

No specialized work crew required. Lights are immediately operational with limited air traffic disruption. The A650 can be quickly relocated for temporary or emergency applications.



Self-Contained and Low Maintenance

All components are incorporated within a compact, stand-alone unit. The A650 airside construction light features a replaceable battery pack that extends the service life beyond 5 years, reducing the total cost of ownership and resulting in significant cost savings.



Unprecedented Reliability

Energy Management System (EMS) monitors and adapts the brightness to environmental conditions for consistent operation and long life under the toughest conditions.



Designed and Tested to Tough Industrial Standards

  • MIL-STD-202G: Humidity, Immersion, Vibration, Shock
  • MIL-STD-810G: Solar Radiation, Salt Fog
  • EN 60945: ESD, EMI, EMC; IP68; L70
  • The A650 is acceptable for barricade and construction applications at Commercial Part 139 Airports under FAA Advisory Circular AC 150/5370-2E.



User Friendly

Easy configuration and programming options include an onboard user interface, an infrared remote and device manager software through USB connection or optional wireless control system offering secure 900 MHz.

Please fill out the form below or call 615.503.2000 with questions or to order this product.


  • Drop files here or
    Accepted file types: jpg, png, pdf.

    Solar Panel
    High-efficiency cells with bypass and blocking diode function
    Maximum power point tracking (MPPT) for optimal energy collection
    Battery
    Tool-less, replaceable and recyclable best-in-class battery pack with extreme temperature range
    Battery status feedback of Good, Charge or Bad (replace)
    2500 cycles or 7-year lifetime on average
    Light Source
    High-powered LEDs
    Color-specific temperature-corrected LED drivers provide consistent intensity under all operating conditions
    Intensity
    Greater than 10 cd intensity, steady-on in certain colors
    Colors
    Red, blue, yellow, green, white
    ICAO and SAE25050 (FAA) compliant chromaticity
    NVG-compatible infrared LEDs (wireless only)
    Color Indicator
    FAA Engineering Brief 67 compliant
    Flash Patterns
    256+ (non-wireless)
    Steady-on mode and flash patterns (wireless)
    Energy Management System (EMS)
    Intelligent microprocessor
    Automatic Light Control (ALC)
    When enabled, automatically adjusts to low amounts of sunlight to ensure continued operation
    Construction
    Premium-grade, UV-resistant polycarbonate/polysiloxane copolymer body and lens material
    Double O-ring sealing with waterproof vent
    Temperature
    -45 to 124 ºF (-43 to 51 ºC) operating
    The A650 will function up to 190 ºF (88 ºC) internal and surface temperatures
    -45 to 176 ºF (-43 to 80 ºC) storage
    Weight
    3.5 lbs (1.6 kg)
    Wind Loading
    400 mph (180 m/s)
    Radio Receiver
    900 MHz ISM (wireless)
    Range
    Up to 2.5 miles (4 km) (wireless)



    Configuration

    ModelOutputSwitchControl
    OL4
    Red
    Blue
    Green
    White
    Yellow
    Non-switched
    Switched*
    Non-wireless
    Wireless

    *A650 Wireless model must have switch

    Compliance

    FAA logo

    ICAO logo

    Intertek A650 compliance to FAA and ICAO lighting standards
    Intertek OL4 ICAO certification

    CE logo

    CE OL4 compliance

    National Technical Systems logo

    NTS explosive atmosphere compliance



    Datasheet

    A650 datasheet
    Solar airfield accessories
    Solar airfield light intensities



    Current Manual

    A650 manual
    A650 Wireless manual
    A650 Wireless manual (Spanish)
    Manuals for older product revisions can be found in the Knowledge Base.



    Quick Start Guide
