FTS 350i Wind Turbine Lighting System

FAA L-864 Wind Farm Lighting

The FTS 350i is an economical FAA L-864 / ICAO Type B red LED lighting system specifically designed for wind turbine applications that do not require the advanced features of the FTS 370i.



Small and light, this stand-alone obstruction light does not have a controller taking up scarce space inside the nacelle. The weather-proof, UV-resistant, polycarbonate construction provides a 90% weight reduction over the FTS 370i.



The FTS 350i is fully compliant with FAA AC 70/7460-1L requirements for turbines with rotor tip heights less than 699 feet and is certified to AC 150/5345-43J with infrared LEDs.



Standard Features

  • Fully integrated system – no external controller
  • Easy to carry and install on turbines due to extremely low weight
  • Infrared (IR) LEDs for compatibility with NVG and NVIS per FAA AC 150/5345-43J
  • Fresnel optics minimize ground scatter, making the light more community-friendly
  • 10kA surge protection, two times the FAA-specified minimum
  • GPS for synchronized flashing
  • Handheld remote controller simplifies light setup
  • Field-configurable flash rate of 20 or 30 fpm
  • Dry contact alarm for beacon, GPS sync and mode change
  • 2-year replacement warranty



Optional Features

  • Adaptor plates for existing mounting brackets
  • Mounting brackets available for multiple turbine manufacturers
  • Overvoltage protection device (OVP)



Product Comparison

FTS 350i

FTS 370i

Surge Protection

10kA

25kA

Warranty

2-year replacement

5-year parts

Weight

2.9 lbs. (1.3 kg)

26.3 lbs. (11.9 kg)

Wind Area

26.8 in2 (17,290 mm2)

99 in² (63,870.8 mm²)

Power Consumption (30 fpm)

9 W

10 W

GPS Sync

Alarm Relay

Infrared LEDs

Radar Interface

Please fill out the form below or call 615.503.2000 with questions or to order this product.

  • Drop files here or
    Accepted file types: jpg, png, pdf.

    Input Voltage

    120-240 VAC

    Frequency

    50-60 Hz

    FH Weight

    2.9 lbs. (1.3 kg)

    FH Aerodynamic Wind Area

    26.8 in2 (17,290 mm2)

    Protection Rating

    IP66

    POWER CONSUMPTION



    20 fpm

    30 fpm

    L-864 red night at 2,000 ± 25% ECD flash intensity

    6W

    9W

    Power consumption is 1 watt in stand-by.

    Dimensions

    FTS 350i dimensions
    FTS 350i bolt hole circle
    FTS 350i adaptor plate
