OL2 Mounting Bracket

OL2 Mounting Bracket w OL2 marker & cableThe OL2 mounting bracket is designed to adapt a 3/4” NPT OL2 mount to an available flashhead mounting plate on top of the tower. It elevates the double L-810 unit 12” above appurtenances, providing 360-degree visibility and ensuring an unobstructed view per FAA AC 70/7460.



* The OL2 mounting bracket kit does not include OL2 or cable.



Standard features

  • Aluminum base mounts to 13.25” flashhead bolt pattern
  • Designed for fast and easy installation
  • Weight: 3.5 lbs (1.59 kg)
  • TIA-222G certified
  • Part number: 3877103



The OL2 mounting bracket assembly includes:

  • Welded base
  • Aluminum tee coupling
  • 3/4” cord grip
  • 12” nipple conduit

An exploded view of the OL2 mounting bracket
